Do in order

Steps that belong together, in the order they have to happen, with a guard at the front that can call the whole thing off.

The problem

The Platformer enemy has to confirm it can see the player before it chases. Get that backwards and the enemy charges at nothing, which is the kind of bug that only shows up when a playtester walks behind a wall. The fix in code is an early return, and early returns spread: one per method, each with its own idea of the precondition.

A Sequence is that precondition made visible. Put the check first, the work second, and the work cannot start on a fact that is false.

When to reach for it

• Guard then act: player is visible, then chase the player, which is the chase branch of DocumentationFlowControls.bqbehavior.
• Ordered work where each step needs the one before it: claim the route, walk to the point, report arrival.
• One branch of a Selector. This is the most common use. The Sequence declines on behalf of the branch, and the Selector moves on.

See it

While the sight check refuses, the tick goes to the search route beside the chase branch; once it holds, the chase Sequence carries the tick into chase the player and keeps it there.

The sight condition succeeds, the cursor moves to the chase action, and the chase holds Running. The Sequence keeps its place on that second child across updates until the chase produces a result.

Do it

1. Open Assets/Platformer/Behavior/DocumentationFlowControls.bqbehavior and select the Sequence called chase player.

2. Read the Children list: player is visible first, chase the player second. That order is the contract.

3. Select player is visible. Its rail reads the blackboard variable player_visible and compares it, which is what makes the branch decline when the player is hidden.

4. Enter Play Mode with an agent on this graph and leave player_visible false. The condition reports Failure and the chase action never starts.

5. Set player_visible to true in the Live blackboard. The condition succeeds and the cursor advances to the chase action on the same update.

Figure 1. The guard is a child, at the front. Reversing these two rows changes behavior even though the picture still looks tidy.

You should see

In Live, the status pill moves along the row: the sight condition reads SUCCESS, then the chase action takes the pill and holds RUNNING. The Sequence and both of its children stay bright as the active path while the rest of the tree dims.

Change one thing

Drag chase the player above player is visible in the Children list. Play again: the chase starts before anything has checked whether there is a target, and the condition result now decides only whether the Sequence finishes clean. Drag it back.

How it decides

A Sequence is the mirror image of a Selector. It keeps a cursor on the child it is working through, and that cursor survives across updates.

Result

Success

Every child returned Success, including the last one.

Failure

A child returned Failure or Blocked. The Sequence stops there and reports that result, and the remaining children do not run.

Running

The current child is Running, or a child just succeeded and the cursor moved to the next one.

• Blocked passes through as Blocked, so a false guard keeps its typed reason on the way up while behaving like a failure to the parent.
• Interrupted, Timeout, and Authority mismatch stop the Sequence and travel to its parent unchanged.
• The cursor is per agent. Two agents on the same graph sit at different steps without interfering, because the cursor lives on the running instance.
• A Sequence does not loop. To run the whole thing again, wrap it in Repeat, which is what EnemyPatrol.bqbehavior does.

When it goes wrong

When it goes wrong

Symptom	Check	Fix
Work happens even though the guard is false.	Read the Children list order for this Sequence.	Move the condition to the first row.
The Sequence finishes once and never runs again.	Look at what sits above it. A bare Sequence runs a single pass.	Wrap it in a Repeat, or let the root complete and restart.
A middle step is skipped.	Check whether the step before it holds Running forever, so the cursor never advances.	Give the long step a result, or bound it with a Time Limit.
Live shows Blocked instead of Failed.	That is a guard predicate reporting false.	Nothing to repair. Composites treat Blocked as a failed step and keep the reason for diagnostics.
Two agents behave as if they share a step.	Confirm each object has its own Behavior Agent rather than one agent driving both.	Give each object an agent. Each instance then owns its own cursor.

Next

• Choose: the Selector that usually sits above a Sequence.
• Keep going: make the whole Sequence repeat.
• Sequence reference: the result table in one box.
